200KW off grid inverter with solar input 400-850VDC without battery system

Model No.︰

SDP-200KW

Brand Name︰

SANDI

Country of Origin︰

China

Unit Price︰

US $ 32000 / pc

Minimum Order︰

1 pc

Share on:

Product Description



200KW off grid inverter with Solar input 400-850VDC wide voltage without storage battery system



Our SDP series Off Grid Pure sine wave inverter is one of the most advanced DC to AC conversion products in the world, it is suitable use for areas without electricity, vehicles, ships, solar energy, wind turbine and other renewable energy systems and etc, can supply power and provide guarantee effectivelyfor the areas with traffic inconveniences, in the mountains, pastoral, border, island and other areas without electricity. It has the main advantages of high quality sine wave AC output, microcomputer control, humanness design, and it is high efficiency and low no-load loss,and no pollution. The inverter can also supply AC power to all kinds of electric equipment, air conditioners, electric motors, refrigerators, fluorescent lights, televisions, electric fans and other industrial power supply.



Technical Features:

  • Using the sixth generation efficient IPM intelligent module from Japanese Mitsubishi, high efficiency and stable performance. It with powerful protection function, the protection for short circuit, over load, over temperature is more safe and reliable. It’s service life can up to 15 years or more.
  • Intelligentized, modularized, simple structure design easy to maintenance.
  • Two kinds of start mode: Reduction Voltage Start and Variable Frequency Start. Customers can set start mode according to the type of their load. This function is very convenient for users and also reduce frequency converter’s usage, which reduced the cost of equipment investment, easy to connect wires and control.
  • The output frequency can be setting via LCD panel, it’s very convenient for customer.
  • The output voltage can be set between -40 % to +20 % of rated voltage. And the output voltage is very accuracy ±1%.
  • The DC input voltage range can be set. Over-voltage point, under-voltage point, over-voltage recovery point, under-voltage recovery point all can be setting via the LCD panel.
  • Pure sine wave output. With good dynamic response less than 50MS, waveform distortion rate smaller, higher conversion efficiency and stable output voltage.
  • Low frequency transformer which ensure the DC busbar and AC busbar are completely isolated to avoid interference.
  • Wide input voltage can be set according to customer’s requirement. Input voltage range can be selected from 100-500V or 200-850V.
  • High conversion efficiency, Max. Efficiency≥96%
  • Adopts black pure aluminum radiator, which confirms the best radiating performance.
  • Powerful data display function. LCD can display the DC input voltage, output frequency, phase voltage, phase current, AC bypass input voltage, output power KWH, time and date, temperature, fault code display.
  • Wide input voltage can be set according to customer’s requirement. Input voltage range can be selected from 100-400V, 200-500V or 200-850V.
  • European CE (EMC, LVD) certificate, accredited by Australian CEC, ERAC energy network.

[Optional]

  • RS485 remote monitoring;
  • Can addAC bypass complementary function;



Technical Parameters (Normal model)



200KW off grid inverter with Solar input 400-850VDC wide voltage without storage battery system





Our SDP series Off Grid Pure sine wave inverter is one of the most advanced DC to AC conversion products in the world, it is suitable use for areas without electricity, vehicles, ships, solar energy, wind turbine and other renewable energy systems and etc, can supply power and provide guarantee effectively for the areas with traffic inconveniences, in the mountains, pastoral, border, island and other areas without electricity. It has the main advantages of high quality sine wave AC output, microcomputer control, humanness design, and it ishigh efficiency and low no-load loss, and no pollution. The inverter can also supply AC power to all kinds of electric equipment, air conditioners, electric motors, refrigerators, fluorescent lights, televisions, electric fans and other industrial power supply.



Technical Features:

  • Using the sixth generation efficient IPM intelligent module from Japanese Mitsubishi, high efficiency and stable performance. It with powerful protection function, the protection for short circuit, over load, over temperature is more safe and reliable. It’s service life can up to 15 years or more.

  • Intelligentized, modularized, simple structure design easy to maintenance.

  • Two kinds of start mode: Reduction Voltage Start and Variable Frequency Start. Customers can set start mode according to the type of their load. This function is very convenient for users and also reduce frequency converter’s usage, which reduced the cost of equipment investment, easy to connect wires and control.

  • The output frequency can be setting via LCD panel, it’s very convenient for customer.

  • The output voltage can be set between -40 % to +20 % of rated voltage.And the output voltage is very accuracy ±1%.

  • The DC input voltage range can be set. Over-voltage point, under-voltage point, over-voltage recovery point, under-voltage recovery point all can be setting via the LCD panel.

  • Pure sine wave output. With good dynamic response less than 50MS, waveform distortion rate smaller, higher conversion efficiency and stable output voltage.

  • Low frequency transformer which ensure the DC busbar and AC busbar are completely isolated to avoid interference.

  • Wide input voltage can be set according to customer’s requirement. Input voltage range can be selected from 100-500V or 200-850V.

  • High conversion efficiency, Max. Efficiency≥96%

  • Adopts black pure aluminum radiator, which confirms the best radiating performance.

  • Powerful data display function. LCD can display the DC input voltage, output frequency, phase voltage, phase current, AC bypass input voltage, output power KWH, time and date, temperature, fault code display.

  • Wide input voltage can be set according to customer’s requirement. Input voltage range can be selected from 100-500V, 200-600V or 400-850V.

  • European CE (EMC, LVD) certificate, accredited by Australian CEC, ERAC energy network.

    [Optional]

  • RS485 remote monitoring;

  • Can add AC bypass complementary function;





PV Off-grid Solar Power System without batteries



200KW off grid inverter with Solar input 400-850VDC wide voltage without storage battery system



Technical Parameters

Model

SDP-200KW

SDP-250KW

Isolation mode

Low Frequency Transformer

Solar Input

Input voltage range (Vdc)

400~800V

400~800V

Rated voltage (Vdc)

600V

600V

Rated current (A)

333A

417A

AC Output

Rated power (KW)

200KW

250KW

Rated voltage

380V±3%

380V±3%

Number of phases

3 phase 4 wire

3 phase 4 wire

Rated current (A)

303A

379A

Rated output voltage range (V)

220/230/240/380/400/415/440/480VAC (optional)

Output frequency

50Hz or 60Hz ±0.05 (Can set)

Waveform

Pure sine wave

Waveform distortion rate  (THD)

Linear load≤2%

Dynamic Response time(Load 0←→100%)

5%, ≤50ms

Power Factor (PF)

0.99

Inverter Efficiency

>93%

Electrical insulation properties

2000Vac,1 Minute

Protection Function

Overload Ability

150%,10s

Protection

Input reverse polarity, under voltage, overvoltage, output over-current, short circuit, overheating etc.

Display

LCD

Communication interface (optional)

RS485 (A,B)

Method of working

Working continuously

Cooling method

Fan-cooled

Short-circuit protection

No automatic recovery, need to restart the machine

Working Environment & Mechanical dimension

Degree of protection

IP20 (indoor)

Working Altitude(m)

≤2500m

Working temperature ()

-15~+50

Relative humidity ()

0~90%, No condensation

Noise ( 1 meter)

≤60dB

Unit size: (W x D x H)

1000x900x1730mm

1200x1200x1860mm

Reference weight (Kg)

850Kg

1100Kg

Our company can adjust parameter configuration according to users requirement.
